Firewall Micro Appliance, Fanless Mini PC Intel N100 Quad Core, DDR5 RAM, VPN, Router PC, AES-NI, 4 Intel 2.5GbE I226-V LAN, Barebone
4.2 (136 items)
Limited Time SaleUS$155.99 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 209118757 | Release Date | 2026/03/29 | List Price | US$104.00 | Model Number | 209118757 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
pros>1. Dual USB3.0 + 4*USB2.0>2. 4*Intel i226-V NIC chip 2.5G built-in filter connector>3. 2*HDMI1.4+DP1.4 triple display interface, support 4K triple display/synchronous heterodyne display>4. 2*M.2 NVMex1 high speed interface and 2*SATA3.0 ports>5. TF card holder support data storage or system boot>6. Small 4PIN fan-powered docking station supports temperature-controlled fan.>7. All-aluminum alloy high-quality solid casing, fanless system, no cooling fan, no noise, durable, suitable for industrial-grade fields, working time up to 7x24 hours.>8. Support AES-NI, TPM2.0, ESXI, PVE, Watchdog, Auto power on, RTC, PXE boot, Wake-on-LAN etc.>9. Low consumption TDP and can be mounted back of monitor by VESA bracket.(Bracket not included)Package List1xMini PC1xPower Adapter1xPower Cord1xSATA Cable1xScrews Bag
- CPU: Intel N100 Small Core Processor quad core 4 threads, 6M Cache, up to 3.40 GHz, supports Inter AES-NI
- Ports: 4*RJ45 LAN/WAN, 4*USB2.0, 2*USB3.0, 1*DC IN, 1*TF solt, 1*Type-C, 2*HDMI 2.1 and 1*DP1.4
- Storage & Memory: The firewall mini pc comes with 1*SO-DIMM DDR5 RAM slot(4800/5200/5600MHz), supports up to 32GB; 2*M.2 NVMe x1 solt and 2*SATA3.0 ports
- 4 Intel I226-V 2.5 NIC Ports: The fanless firewall mini PC is powered by Intel i226-V NIC chips, which supports 4 2.5 Gigabit Ethernet and is more stable, faster and consumes less power than i225 NIC. It has good compatibility with soft routes, firewalls and other network applications
- Compatibility: No pre-installed operating system. All hardware has been tested with OPNsense, untangle, Windows, Proxmox and other popular open source software solutions
| Brand | ZHIANN |
|---|---|
| Color | Black |
| RAM Type | DDR5 SDRAM |
| Model Name | Firewall Miceo Appliance/Mini PC |
| Resolution | 3840 x 2160 |
| Style Name | Inter Processor N100 |
| Aspect Ratio | 1.85:1 |
| Display Type | External |
| Manufacturer | ZHIANN |
| Memory Speed | 4800 MHz |
| Model Number | ZHI-V2-N100-0-0 |
| Video Output | HDMI or DisplayPort |
| BuiltIn Media | no |
| Cooling Method | Passive, Aluminum Alloy Heat Sink |
| Item Dimensions | 7.02 x 5.33 x 2.17 inches |
| Processor Brand | Intel |
| Processor Count | 4 |
| Processor Speed | 3.4 GHz |
| Total Usb Ports | 8 |
| Video Processor | Intel |
| CPU Model Number | Inter N100 |
| Operating System | Windows, pfsense, OPNsense, etc |
| Processor Series | Celeron |
| Processor Socket | FCBGA1264 |
| Graphics Ram Type | DDR5 SDRAM |
| Native Resolution | 3840 x 2160 |
| Power Consumption | 6 Watts |
| Hardware Interface | DisplayPort, Ethernet, HDMI, USB |
| Memory Clock Speed | 5600 MHz |
| Additional Features | Firewall Mini PC |
| Hard Disk Interface | Solid State |
| Wireless Technology | Wi-Fi |
| Graphics Coprocessor | Integrated Graphics |
| Graphics Description | Integrated |
| HumanInterface Input | Keyboard |
| Keyboard Description | Dialing keys |
| Warranty Description | 6 months |
| Hard Disk Description | SSD |
| RAM Memory Technology | DDR5 |
| Memory Slots Available | 1 |
| Video Output Interface | HDMI, DisplayPort |
| CPU Model Speed Maximum | 3.4 GHz |
| Connectivity Technology | Ethernet, HDMI, LAN |
| Graphics Card Interface | PCI Express |
| Ram Memory Maximum Size | 32 GB |
| Specific Uses For Product | Everyday Use |
| Display Resolution Maximum | 3840 x 2160 pixels |
| Total Number of HDMI Ports | 1 |
| Number of Component Outputs | 3 |
| Wireless Network Technology | Wi-Fi |
| Personal Computer Design Type | Mini PC |
